Appendix B Parameter Table
-
357
-
Function
Code
Name Setting Range Default Unit Property Page
F9-03 Clock: year 2000 to 2100
Current
time
YYYY
☆
P231
F9-04 Clock: month 1 to 12
Current
time
MM
☆
F9-05 Clock: day 1 to 31
Current
time
DD
☆
F9-06 Clock: hour 0 to 23
Current
time
HH
☆
F9-07 Clock: minute 0 to 59
Current
time
MM
☆
F9-09 Accumulative running time 0 to 65535 0 h 
F9-11 High byte of running times 0 to 9999 0 - 
F9-12 Low byte or running times 0 to 9999 0 - 
F9-13
󶍾
period
0 to 99 0 day
★
Group FA: Keypad setting parameters
FA-00 Keypad display selection
󶍿
󶍿
󶍿
󶍿
3 -
☆
P232
FA-01 Display in running state 1 to 65535 65535 -
☆
FA-02 Display in stop state 1 to 65535 65535 -
☆
P233
FA-03 Current encoder angle 0.0 to 359.9 0.0
Degree
(° )

P234
to
P236
FA-05 MCB board software 0 to 65535 0 - 
FA-06 Drive board software 0 to 65535 0 - 
FA-07 Heatsink temperature 0 to 100 0 ºC 
FA-11 Pre-torque current 0.0 to 200.0 0 % 
FA-12 Logic information 0 to 65535 0 - 
FA-13 Curve information 0 to 65535 0 - 
P236
to
P237
FA-14 Set speed 0.000 to 4.000 0 m/s 
FA-15 Feedback speed 0.000 to 4.000 0 m/s 
FA-16 Bus voltage 0 to 999.9 0 V 
FA-17 Current position 0.0 to 300.0 0 m 
FA-18 Output current 0.0 to 999.9 0 A 
FA-19 Output frequency 0.00 to 99.99 0 Hz 
FA-20 Torque current 0.0 to 999.9 0 A 
FA-21 Output Voltage 0 to 999.9 0 V 
FA-22 Output torque 0 to 100 0 % 
FA-23 Output power 0.00 to 99.99 0 kW 
FA-24 Communication interference 0 to 65535 0 - 
FA-26 Input state 1 0 to 65535 0 - 
P237
to
P240
FA-27 Input state 2 0 to 65535 0 - 
FA-28 Input state 3 0 to 65535 0 - 
FA-30 Input state 5 0 to 65535 0 - 
FA-31 Output state 1 0 to 65535 0 - 
FA-32 Output state 2 0 to 65535 0 - 
FA-33 Car input state 0 to 65535 0 - 
P240
FA-34 Car output state 0 to 65535 0 - 
FA-35 Hall sate 0 to 65535 0 - 
P241FA-36 System state 1 0 to 65535 0 - 
FA-37 System state 2 0 to 65535 0 - 
FA-38
󶍿
interval
0 to 200 0 s  P242
FA-46 Hall call communication state 1 󶍿 0 - 
P242
FA-47 Hall call communication state 2 󶍿 0 - 
FA-48 Hall call communication state 3 󶍿 0 - 
FA-50
Expansion board hall call
communication state 1
󶍿 0 - 
FA-51
Expansion board hall call
communication state 2
󶍿 0 - 
FA-52
Expansion board hall call
communication state 3
󶍿 0 - 
