Appendix B Parameter Table
-
358
-
Function
Code
Name Setting Range Default Unit Property Page
FA-58 Version display selection
0: Machine-room-less monitoring board
version
1: Equipment room expansion board version
2: Car expansion board version
3: ARD version
4: AFE master version
5: AFE slave version
0 -
☆
P243
FA-59
Expansion board software
version
0 to 65535 0 -
Group Fb: Door function parameters
Fb-00 Number of door machine(s) 1 to 2 1 -
★
P243
Fb-01 CTB software 00 to 999 0 -
Fb-02 0 to 65535 65535 -
☆
P244
Fb-03 0 to 65535 65535 -
☆
Fb-04 0 to 65535 65535 -
☆
Fb-05 0 to 65535 65535 -
☆
Fb-06 Door open protection time 5 to 99 10 s
☆
Fb-07 Arrival gong output delay 0 to 1000 0 ms
☆
Fb-08 Door close protection time 5 to 99 15 s
☆
Fb-09
Door open/close protection
times
0 to 20 0 -
☆
P245
Fb-10 Door state of standby elevator
0 -
☆
Fb-11
Door open holding time for hall
call
1 to 1000 5 s
☆
Fb-12
Door open holding time for car
call
1 to 1000 3 s
☆
Fb-13
Door open holding time at base
1 to 1000 10 s
☆
Fb-14 Door open delay 10 to 1000 30 s
☆
Fb-15 Special door open holding time 10 to 1000 30 s
☆
P246
Fb-16
Manual door open holding
time
1 to 60 5 s
☆
Fb-17
Holding time for forced door
close
5 to 180 120 s
☆
Fb-18 0 to 65535 65535 -
☆
Fb-19 0 to 65535 65535 -
☆
Fb-20 Manual door lock waiting time 0 to 60 0 -
☆
Fb-24 UCMP test program version 0 to 65535 1 -
Group FC: Protection function parameters
FC-00
F5-33 Program control
selection
Bit0: Detection of short circuit to ground at
power-on
Bit2: Decelerating to stop at valid light
curtain
Bit9: Mode without door open/close limit
0 -
★
P246
to
P247
FC-01 Function selection
Bit0: Overload protection
Bit1: Canceling protection at output phase
loss
Bit4: Light curtain judgment at door close
limit
Canceling DSP communication test
Bit14: Canceling protection at input phase
loss
65 -
★
