Appendix B Parameter Table
-
364
-
Function
Code
Name Setting Range Default Unit Property Page
E9-00 10
th
fault code 0 to 9999 0
P260
to
P261
E9-01 10
th
fault subcode 0 to 65535 0
E9-02 10
th
fault month and day 0 to 1231 0 MM.DD
E9-03 10
th
fault hour and minute 0 to 23.59 0 HH.MM
E9-04 10
th
fault logic information 0 to 65535 0
E9-05 10
th
fault curve information 0 to 65535 0
E9-06 Speed reference upon 10
th
fault 0.000 to 4.000 0 m/s
E9-07 Feedback speed upon 10
th
fault 0.000 to 4.000 0 m/s
E9-08 Bus voltage upon 10
th
fault 0 to 999.9 0 V
E9-09 Present position upon 10
th
fault 0.0 to 300.0 0 m
E9-10 Output current upon 10
th
fault 0.0 to 999.9 0 A
E9-11
Output frequency upon 10
th
fault
0.00 to 99.99 0 Hz
E9-12 Torque current upon 10
th
fault 0.0 to 999.9 0 A
E9-13 Output voltage upon 10
th
fault 0 to 999.9 0 V
E9-14 Output torque upon 10
th
fault 0 to 200.0 0 %
E9-15 Output power upon 10
th
fault 0.00 to 99.99 0 kW
E9-16
Communication interference
upon 10
th
fault
0 to 65535 0
P261
E9-17
Encoder interference upon 10
th
fault
0 to 65535 0
E9-18 Input state 1 upon 10
th
fault 0 to 65535 0
E9-19 Input state 2 upon 10
th
fault 0 to 65535 0
E9-20 Input state 3 upon 10
th
fault 0 to 65535 0
E9-21 Input state 4 upon 10
th
fault 0 to 65535 0
E9-22 Input state 5 upon 10
th
fault 0 to 65535 0
E9-23 Output state 1 upon 10
th
fault 0 to 65535 0
E9-24 Output state 2 upon 10
th
fault 0 to 65535 0
E9-25 Car input state upon 10
th
fault 0 to 65535 0
E9-26 Car output state upon 10
th
fault 0 to 65535 0
E9-27 Hall call state upon 10
th
fault 0 to 65535 0
E9-28 System state 1 upon 10th fault 0 to 65535 0
E9-29 System state 2 upon 10th fault 0 to 65535 0
