Instron 6800 - Operator Protection Overview

Chapter: Risk reduction and safe use
36 M10-17547-EN
1. Discontinue testing immediately and turn off the power to the equipment. Unplug the
power cord (if applicable).
2. Clean up as much spilled liquid as possible on the outside of the equipment. Be sure
to check underneath rubber mats (if present) and any installed accessories.
3. If you have reason to believe that liquid entered the testing system, contact Instron
®
Service.
a The service engineer will remove the covers of the equipment and clean up all
traces of spilled liquid.
b Any components damaged by liquid may need to be replaced.
c The service engineer will perform an operational check to verify proper function
of safety systems.
Warning
Continuing to operate a testing system after liquid has entered the testing system may
pose a hazard to the operator and lead to additional equipment damage.
4. Resume testing only after the liquid spill has been properly cleaned up. If the testing
system exhibits any faults or unexpected behavior, discontinue testing immediately
and contact Instron
®
Service.
Operator Protection Overview
The majority of hazards for operating materials testing systems are associated with:
• rapid movement of the crosshead causing crush injuries
• rapid closing of pneumatic grips causing pinch injuries
Operator Protection in Bluehill
®
provides a mechanism that lets you limit crosshead jog
speed and reduce grip closing pressure while you are setting up a test.
The default conditions during test set up are:
• crosshead jog speed reduced to a maximum of 600 mm/min, and can be set lower
if your risk assessment requires it
• grip closing pressure reduced to a default of 15 psi, and can be set lower if your risk
assessment requires it.
