Instron 6800 - Installation; Power Supply Compatibility

39
Product Support: www.instron.com
Chapter 4
Installation
• Power supply compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
• System components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
• First time startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Power supply compatibility
The first step in the installation is to verify that the voltage and electrical plug are
compatible with the location’s power supply.
The power cord set and plug is based on the country to which the equipment was
shipped and is compatible with the electrical requirements for that country.
Warning
Frames may overheat or suffer damage if connected to a power supply greater than
15% above the configured voltage.
Caution
Frames may not be able to run at rated speeds if connected to a power supply more
than 10% below the configured voltage.
Before proceeding with installation, verify the following:
• The equipment voltage is compatible with the main power supply of your facility.
Refer to “Determine the voltage setting” on page 41.
• The equipment power cable can reach the electrical power supply with some slack
in the cable.
• The plug is compatible with the electrical power outlet.
