Chapter: Function of controls
74 M10-17547-EN
If the grips feature an air inlet flow adjustment control (see below), make sure that
the flow adjustment is set to fully open (screw fully counterclockwise).
Do not use the air inlet flow adjustment control to reduce air flow as you risk
transitioning from initial pressure to full pressure before the grips have closed. If the
grips do not close completely at the initial pressure, they will close at full force when
the grips transition to full pressure.
In addition to the hazard caused by reducing the air flow, operation of the air inlet flow
adjustment control can result in an inaccurate grip pressure reading which may disable
the frame.
You can remove the air inlet flow adjustment control and connect the 1/8” NPT quick
disconnect directly to the grip or via a 1/8” NPT right angle male to female adapter, as
shown below.
