Chapter 1: Introduction
10 M47-17028-EN
System overview
Purpose
The Instron Model DX Static Hydraulic Universal Testing Systems are available in a variety of capacities.
They have been developed for high-capacity testing to provide the forces necessary for static tension,
compression, bend and shear testing. They are suited for tests on specimen samples such as bar, rebar,
plate, tube, pipe, sheet, wire, and concrete. These frames feature two test spaces so that users can
quickly change between tension and compression testing without having to remove heavy fixtures. This
flexible design helps to ensure safety, reduce operator fatigue and improve productivity.
System components
Model DX systems consist of:
• Frame
• Hydraulic Power Supply (HPS)
• 59 Series control unit and other system controls and electronics
• Instron approved computer system with Instron materials testing software
Figure 1 identifies the system components and various frame configurations (see “Frame
configuration options” on page 12).
If the equipment is used in a manner not specified by Instron, the protection provided by the
equipment may be impaired. Injury to personnel or damage to the system may result. Be
sure to read and understand the material presented in these instructions and in any other
accompanying instructions.
