Instron DX Series System Concepts Manual

17
Interconnections
Product Support: www.instron.com
Electrical interconnections
Before making electrical interconnections, all system components (including the computer system)
should be unpacked and in place at the installation site. Also, the computer system components can and
should be interconnected as outlined by the computer manufacturer. Check the electrical nameplate of
each computer component and connect to an appropriate power source.
Refer to Table 1 as you step through the interconnection process.
Table 1. Electrical connections required.
Cable Connect From Connect To
Ethernet crossover cable, male RJ45 Auxiliary Ethernet connection on
rear of computer
Ethernet connection on 59 Series
control unit
Load transducer cable, male 25-pin LOAD connection on 59 Series
control unit
Load transducer on frame
Position cable, male 9-pin Hardwired to frame interface
board inside base of frame
Position encoder on frame
1
For systems that include an optional
enclosure
Interlock cable
Connection on side of frame base
above 59 Series control unit
Enclosure interlocks - typically
routed along inside of enclosure to
its exit point
Frame main power cable Frame (hardwired to frame) Customer power supply of
appropriate rating
For systems that include the optional
Versachannel or Multichannel
Coaxial cable, male BNC
SYNC (BNC) connection on
59 Series control unit
BNC connection on the
Versachannel or Multichannel box
For systems that include the optional
Expansion Channel Module
68-Way mini-D cable
Expansion port on 59 Series
control unit
X1 connection on rear of
Expansion Channel Module box
1. Encoder cable may have been disconnected from encoder for shipment. Cable remains hardwired to frame
interface board. Connect cable end to encoder on bottom of hydraulic cylinder.
