Instron DX Series User Manual

15
System overview
Product Support: www.instron.com
Frame components
Refer to Figure 2 and Table 1 to identify components of the frame. For proper operation of the system,
it is important to be able to identify and to understand the basic function of these components.
Figure 2. DX frame components - for legend see Table 1.
1
2a
1
8
6
9
4a
5
2b
3a
1
1
3b
4b
View B
Fixed Unit
Frame with
G8-style
crossheads
Frame with
G1-style or
G7-style
crossheads
View A
Loading Unit
7
