Instron DX Series User Manual

89
Spare and replacement parts
Product Support: www.instron.com
Consumable parts
DX systems are designed to require very few parts to be replaced during their lifetime. These consumable
parts are listed in Table 18. The replacement frequency of each part, or the condition that indicates that
replacement is necessary, is discussed throughout this chapter.
Spare and replacement parts
The Instron Services department can supply parts for your system. In the event that your system requires
replacement parts, or if you choose to keep spare parts in stock, please contact your local Instron
Services department as directed on page 20 for the proper part.
Table 18. Consumable parts list.
Description Location or Purpose Frame Model Part Number
1
Lubricant, Molykote GN metal paste,
0.45 kgs (1 lbs) can
Lubricate grip
assemblies
300DX-G1
600DX-G1
300-8894-9035
Lubricant, Molykote GN metal paste,
0.4 kgs (14 oz) cartridge
Lubricate grip
assemblies
300DX-G7
600DX-G7
300-8894-9059
Adhesive, Loctite 246 Threadlocker high
temperature/medium strength, 10 mL (0.34 oz)
Maintain grip
assemblies
300DX-G7
600DX-G7
300-8899-10741
Cleaner and degreaser, Loctite 7070 ODC-FREE,
475mL (16oz) spray
Maintain grip
assemblies
300DX-G7
600DX-G7
300-8899-10742
Lubricant, Molykote BR2 Plus,
0.4 kgs (14 oz) cartridge
Lubricate backlash
eliminators
All 105-1-60
Lubricant, Molykote BR2 Plus,
16 kgs (35 lbs) can
Lubricate screw
columns
All 300-8894-9064
Oil filter element (3 micron) HPS - oil filter All 300-8873-9150
Air breather filter HPS - reservoir All 300-8868-9091
1. Part numbers are listed for reference only. Some parts can not be ordered using these numbers; contact your local
Instron Services department as directed on page 20 to order parts.
