Instron DX Series User Manual

Chapter 4: Maintenance
86 M47-17027-EN
Ancillary parts
DX systems are provided with operating tools and other accessories that are either: required to complete
installation of the frame; required for use or maintenance of frame; or required for set up of accessories
on the frame. These ancillary parts are included with the frame upon delivery. Ancillary parts for the
various DX systems are listed in Table 17. Be sure to keep these ancillary parts in a safe place so they
do not get misplaced.
Table 17. Ancillary parts list.
Description Location or Purpose Frame Model Part Number
1
Quantity
Grip stop plate Grip assemblies - tension crosshead 300DX-G1 228133-1 1
600DX-G1 225769-1 1
Jaw retainer Grip assemblies - tension crosshead 300DX-G1 228134-2 4
600DX-G1 225768-2 4
Button head cap screw,
5/16-18 x 0.5 in
Grip assemblies - secure jaw retainer
300DX-G1 300-8826-1020 8
Button head cap screw,
3/8-16 x 0.75 in
600DX-G1 300-8826-1027 8
Socket head cap screw,
M10 x 1.5p x 35 mm
Grip assemblies - secure grip stop
plate to tension crosshead
300DX-G1 300-8821-9310 2
Socket head cap screw,
M16 x 2p x 35 mm
600DX-G1 300-8821-9511 2
Filler plate, 3/16 in thick Grip assemblies 300DX-G1 109797-1-1 12
600DX-G1 126509-1B 16
Pinion Grip assemblies 300DX-G1 228377-2 2
600DX-G1 228143-2 2
Setscrew,
M10 x 1.5p x 25 mm
Grip assemblies - secure pinion in
crosshead
300DX-G1
600DX-G1
300-8822-9522 2
Crank handle Grip assemblies 300DX-G1
600DX-G1
300-8876-1006 2
Wear plate Extra set for grip assemblies 300DX-G7 221722-1 4
600DX-G7 225566-1 4
Grip dust cover, rubber Extra set for grip assemblies 300DX-G7 227831-1 4
600DX-G7 225752-1 4
Piston dust cover Grip assemblies 300DX-G7 221174-1 2
600DX-G7 225751-1 2
Bumper plate Compression test space - mount to
bottom of adjustable crosshead
300DX-G8 217481-2 1
300DX-G1
300DX-G7
600DX-G1
600DX-G8
226722-3 1
