Chapter 3: Operation
36 M47-17027-EN
Figure 8. Example of bumper plate.
1. Bumper plate (typical)
2. Setscrew, M8
3. Button hole, 25 mm (1 in) diameter
4. Mounting button
5. Compression fixture
1
2
3
4
5
