Instruo arbhar - Grain Window, Pitch Deviation, Dub CV Inputs; Mod and Dry;Wet Mix CV Inputs

35
Grain Window CV Input: The Grain Window CV Input is a bipolar
control voltage input for the Grain Window parameter.
• Control voltage is summed with the knob position.
• Input range: 10V. e.g. a voltage difference of 10V is needed to
control from the minimum to maximum knob position. If the knob is at
its centre position, the accepted input range is -/+5V.
Pitch Deviation CV Input: The Pitch Deviation CV Input is a bipolar
control voltage input for the Pitch Deviation parameter.
• Control voltage is summed with the knob position.
• Input range: 10V. e.g. a voltage difference of 10V is needed to
control from the minimum to maximum knob position. If the knob is at
its centre position, the accepted input range is -/+5V.
Dub CV Input: The Dub CV Input is a bipolar control voltage input for
the Dub parameter.
• Control voltage is summed with the knob position.
• Input range: 10V. e.g. a voltage difference of 10V is needed to
control from the minimum to maximum knob position. If the knob is at
its centre position, the accepted input range is -/+5V.
Mod CV Input: The Mod CV Input is a bipolar control voltage input
for the Hardware Configuration set by the Hardware Configuration
Switches (See the Hardware Configurations section for
more information).
• Input range: -/+5V.
Dry/Wet Mix CV Input: The Dry/Wet Mix CV Input is a bipolar
control voltage input for the Dry/Wet Mix parameter.
• Control voltage is summed with the knob position.
• Input range: 10V. e.g. a voltage difference of 10V is needed to
control from the minimum to maximum knob position. If the knob is at
its centre position, the accepted input range is -/+5V.
