Delay Mode Dry/Wet Mix:
Summary: arbhar is set to it’s Feedback/Delay Hardware
Configuration (See the Hardware Configurations section for more
information). When both Output 1 and Output 2 are connected, Output
1 generates the dry signal only and Output 2 generates the wet signal
only. Patching the outputs to two attenuators allows for level control
over the dry/wet mix separately. The dry and wet outputs are summed
together and monitored. Sending CV to the MOD CV Input controls
arbhar’s curated Feedback/Delay parameter.
Audio Path:
• Connect any audio signal to the Input.
• Set the Input Level to a desired position and set the Output Level
fully clockwise.
• Set the Dry/Wet Mix knob to a desired position. If the Dry/Wet
Mix knob is fully clockwise (fully wet), then audio will not be heard
until audio has been captured.
• Connect Output 1 to the input of a VCA for attenuated level control
of the dry signal. Set to a desired amount.
