CV Expansion
Spray CV Input: The Spray CV Input is a bipolar control voltage input for
the Spray parameter.
• Control voltage is summed with the knob position.
• Input range: 10V. e.g. a voltage difference of 10V is needed to
control from the minimum to maximum knob position. If the knob is at
its centre position, the accepted input range is -/+5V.
Layer CV Input: The Layer CV Input is as bipolar control voltage input
for the Layer parameter.
• More than 360 degrees of movement is accessible via positive and
negative control voltage.
• Input range: -/+5V.
• Modulating the Layer parameter between 0V and 5V with external
control voltage will enable two clockwise cycles through all six
layers from the currently selected layer.
• Modulating the Layer parameter between 0V and -5V with external
control voltage will enable two anticlockwise cycles through all six
layers from the currently selected layer.
Grain Direction CV Input: The Grain Direction CV Input is a bipolar
control voltage input for the Grain Direction parameter.
• Control voltage is summed with the knob position.
• Input range: 10V. e.g. a voltage difference of 10V is needed to
control from the minimum to maximum knob position. If the knob is at
its centre position, the accepted input range is -/+5V.
