CombiLock 200 simplex / pro / RFID
Handbuch V.1.05 64 Manual V. 1.05
6 Trouble Shooting
6.1 Optic and Acoustic Signals
Signal
Reason
Comment
2 x
Electronic lock off
In order to switch on, press  for
2 sec.
Q green 1 x
Correct code entry.
Q red and 12 x
Incorrect code entry.
A lockout / blocked time of 10 sec.
follows after the code has been entered
incorrectly 4 times in succession. Each
additional incorrect entry prolongs the
lockout by 10 sec. Enter PIN and valid
Code two times after the lockout
ends.
Q green and 2 x
Modification /
Change OK.
The CODE change or the activation /
deactivation of a supplementary function
has been carried out properly.
Q red and 12 x 
Invalid attempt at
change.
Code change or switching on or off an
additional function carried out
incorrectly. Repeat process.
Q green flashes every
5 sec.
Timed delay is
running.
The electronic lock does not respond to
any key entry while the timed delay is
running.
15 x  then Q green
Release time is
running (Time delay
has ended).
See section 3.8, Opening with Time
Delay, Alarm Delay and Release Time.
Q red flashes every 5
sec.
Lockout / blocked
time is running.
Lockout / blocked time cannot be
discontinued / interrupted!
Q green and 2 x
Lockout / blocked
time has ended.
Signal indicating that the electronic
lock can be opened with the correct
Code.
Q red and green flash
intermittently 10 x and
10 x 
Battery charge low
– Warning.
2 x 1.5 volt MICRO batteries
Type AAA Alkaline (not rechargeable)
should be replaced shortly.
Codes remain the same after
battery change. Enter PIN and code
twice after replacing the battery.
Q green and 1 x  ,
then
Q red and 1 x 
Keypad has been
tampered with or
changed, battery
compartment has
been opened.
In order to open the electronic lock,
enter PIN und CODE once again.
