INTEC Controls | 12700 Stowe Drive, Suite 100, Poway, CA 92064 | Ph: (858) 578.7887 & (888) GO.INTEC | inteccontrols.com
Specifications subject to change without notice. | GAGC06_E_0516 | USA 200303 | Page 25 of 41
DGC6 – UserManual
4.8.2.1 Relay Mode
Denition of the relay mode.
Symbol Description Default Function
Used Mode Used
Used = Relay is registered on the controller and can be used
Not Used = Relay isn’t registered on the controller
4.8.2.2 Relay Mode
Denition of the relay operation mode
The terms energized / de-energized for this item come from the terms open-circuit and closed-circuit principle used for
safety circuits. Here, however, not the relay contact circuit is meant (as a changeover contact, optionally available in
the two principles), but the activation of the relay coil.
The LEDs attached to the modules show the two states in analogy. (LED o󰀨 -> relay de-energized).
Symbol Description Default Function
De-energ. Mode De-energ.
De-energ. = Relay (and LED) de-energized, if no alarm active
Energized = Relay (and LED) permanently energized, if no
alarm active
4.8.2.3 Relay Function Steady / Flash
Denition of the relay function
The function “Flashing” represents a connection option for warning devices to improve visibility. If “Flashing” is set, this
mustn’t be used as a safe output circuit.
A combination of relay mode energized with ashing operation makes no sense and is therefore suppressed.
Symbol Description Default Function
ON Function ON
ON  = Relay function ashing at alarm ( = time xed 1 s)
impulse / break = 1:1
OFF = Relay function static ON at alarm
4.8.2.4 Alarm Trigger Quantity
In some applications it is necessary that the relay switches only at the nth alarm. Here you can set the number of
alarms necessary for relay tripping.
Symbol Description Default Function
Quantity Function 1 Only if this quantity is reached the relay trips.
4.8.2.5 Horn Function
The horn function is considered active if at least one of the two parameters (time or assignment to digital input) is set.
The horn function retains its functionality even for alarms in latching mode.
Symbol Description Default Function
Recurrence Reset mode 0
0 = Reset of the relay after time having run out via DI (external)
or by pushbuttons
1 = After reset of the relay, time starts. At the end of the set
time, the relay is activated again (recurrence function).
Time 120
Enter time for automatic reset function or recurrence function in s
0 = no reset function
DI 0 Assignment, which digital input resets the relay.
