DGC6 – UserManual
4.8.3.3 Selection Gas Type with Unit
Selection of the desired and connected gas sensor type (connection possible as digital sensor cartridge SC, SX or
analog measuring signal MC2)
The selection contains all necessary information for the controller, and is also used for comparing the real, digital data
with the settings.
This feature increases the user and operating security.
There is an entry available per gas type for each unit; at the moment there are 100 selection options.
Code Gas Type Formula Meas. Range
1
Unit
1110 Carbon monoxide CO 0-300 ppm
D110 Carbon monoxide CO 0-5 % Vol
D110 Carbon monoxide CO 0-2000 ppm
1130 Nitrogen dioxide NO2 0-30 ppm
1129 Nitrogen monoxide NO 0-100 ppm
1195 Oxygen O2 0-25 % Vol
1125 Ammonia NH3 0-300 ppm
D164 Carbon dioxide CO2 0-2000 ppm
S164 Carbon dioxide CO2 0-2000 ppm
D164 Carbon dioxide CO2 0-5 % Vol
S164 Carbon dioxide CO2 0-5 % Vol
I164 Carbon dioxide CO2 0-100 % Vol
3400 Methane CH4 0-100 % LEL
I400 IR-Methane CH4 0-100 % LEL
I400 IR-Methane CH4 0-100 %Vol
3480 Propane C3H8 0-100 % LEL
I480 IR-Propane C3H8 0-100 % LEL
I480 IR-Propane C3H8 0-100 % Vol
3440 Hydrogen H2 0-100 % LEL
3408 Ammonia NH3 0-100 % LEL
3485 Acetone (CH3)2CO 0-100 % LEL
3430 Benzene C6H6 0-100 % LEL
3425 Ethyl alcohol C2H5OH 0-100 % LEL
3427 Ethyl acetate CH3COOC2H5 0-100 % LEL
3410 Ethylene C2H4 0-100 % LEL
3460 n-Butane C4H10 0-100 % LEL
3491 n-Heptane C7H16 0-100 % LEL
3435 n-Hexane C6H14 0-100 % LEL
3445 Isopropyl alcohol (CH3)2CHOH 0-100 % LEL
3498 JP8 JP8 0-100 % LEL
3450 Methanol CH3OH 0-100 % LEL
3458 Methyl ethyl ketone MEK C4H8O 0-100 % LEL
3470 n-Octane C8H18 0-100 % LEL
