DGC6 – UserManual
4.2 Status Alarm
Displays the actual alarms in plain text in the order of their occurrence. Only those sensor points are displayed, where
at least one alarm has exceeded its alarm threshold. Changes are not possible in this menu.
Acknowledge latching alarms.
DP 4
Acknowledge?
DP 4
‘S1 ‘S2 ‘S3 ‘S4
Stage Status
Main menu Submenu 1
Symbol Description Function
AP X Measuring Point No. Analog measuring point X = 1 - 32, where an alarm is pending.
DP X Measuring Point No.
Digital measuring point X = 1 - 96, where an alarm is pending.
‘S1
S1
Alarm status
‘S1 = Local alarm 1 active (generated in the sensor / module)
S1 = Alarm 1 active (generated in the central control)
4.3 Status Relay
Displays the current status of alarm and signal relays.
The manual operation (test function) of the alarm and signal relays is performed in the menu Parameters.
Selection of signal relay (1-96)
Alarm Relay 1
Status OFF
Alarm Relay
Status
Signal Relay 1
Status OFF
Signal Relay
Status
Main menu
Selection of alarm relay (1-32)
Submenu 1
4.4 Menu Sensor Readings
In this menu, the display shows the measured values with gas type and unit. If the alarm evaluation is dened as
average, the display shows the current value (C) and additionally the average value (A).
1
D1 CO ppm
A! 120.0A 150.0C
Main menu Submenu
D1 CO ppm
#! 120.0A 150.0C
A1 CO ppm
?! 132.7A 162.7C
