DGC6 – UserManual
4.6.3 CV Log Rate
Setting of the time interval in which the current values of all registered SP are stored (in seconds).
Symbol Description Setting Status Function
10s
Time in
seconds
10s
Time interval between two entries in the CSV le
(10- 9999 sec = approx. 2.7 h )
4.6.4 Alarm Status
Symbol Description Setting Status Function
OFF Alarm status OFF
OFF = Alarms aren’t stored.
ON = Alarms are stored.
Release of the alarm recording for all active measuring points on the USB device into a separate CSV le for alarms
and faults.
The name of the le structured as follows:
AEMMTT.csv, with MM standing for the current month and TT standing for the current day.
Every day, a new le with the current date is generated. This makes sure that the les won’t be too big to be still edited
by established PC programs.
Internal structure of the le
(The headlines are not written in the le!)
Time SP Gas CV AV A1 A2 A3 A4
09_49_47 DP 02 CO 84 84 40 80
09_49_47 DP 03 CO 194 194 40 80 100 100
09_50_02 DP 02 CO 20 20
09_50_02 DP 03 CO 20 20
The rst column gives the time, the second the SP address and the third the gas type.
In the fourth column there is the current value.
The fth column displays the average value.
In the sixth column there is A1, if the rst alarm is active, in the seventh column A2, if second alarm is active and so on
until the fourth alarm.
All active alarms of the SP are always written if there is any change of an alarm. The reset of an alarm is documented
by an empty column. This shows how long the alarm has been active.
