DGC6 – UserManual
4.8.2.7 Delay Mode of Alarm / Signal Relay
Denition of the switch-on and switch-o󰀨 delay of the relays
If the latching mode is set for this relay, the respective switch-o󰀨 delay is without e󰀨ect.
Symbol Description Default Function
0 s
Switch-ON
Delay Time
0
Alarm / Signal Relay is only activated at the end of the dened
time. 0 sec. = No delay
0 s
Switch-OFF
Delay Time
0
Alarm / Signal Relay is only deactivated at the end of the dened
time. 0 sec. = No delay
4.8.2.8 OR Operation of Fault to Alarm / Signal Relay
Enables or disables the Fault OR operation of the current alarm / signal relay.
If the OR operation for this relay is set to active = 1, all device faults will activate the output in addition to the alarm
signals.
In practice, this ORing will be used if, for example, fans should run or warning lights should be activated in case of
device malfunction, since the fault message of the central control is not permanently monitored.
Note:
Exceptions are all errors of the measurement point because the SPs can be assigned to each alarm separately in the
menu SP Parameters. This exception is used to build up targeted zone related signaling in case of SP errors, which
should not a󰀨ect other zones.
Symbol Description Default Function
0
No
assignment
0 Alarm and/or signal relay isn’t a󰀨ected if a device fault occurs.
1
Activated
assignment
0 Alarm and/or signal relay turns on if a device fault occurs.
4.8.2.9 OR Operation of Maintenance to Alarm / Signal Relay
Enables or disables the Maintenance OR operation of the current alarm / signal relay.
If the OR operation for this relay is set to active = 1, the output will be activated in addition to the alarm signals when at
least one maintenance message is pending.
In practice, this ORing will be used if, for example, fans should run when the sensor accuracy isn’t ensured anymore
because of missing calibration (therefore pending maintenance message) or warning lights should be activated, since
the maintenance information of the central control is not permanently monitored.
Note:
Resetting of the activated maintenance message is only possible by calibration of the sensors or by disabling this OR
function.
Symbol Description Default Function
0
No
assignment
0
Alarm and/or signal relay isn’t a󰀨ected if a maintenance message
occurs.
1
Activated
assignment
0
Alarm and/or signal relay turns on if a maintenance message
occurs.
