DGC6 – UserManual
4.6 Menu Data Logger
Connect an USB device at the USB cable to use the data logger function.
This USB device may be for example an USB stick version 2.0 (not all types have been tested).
In this menu, the parameters for the long-term recording of the USB device are set.
Data Logger
OFF
Current Values
OFF
CV Log Rate
15s
Stage Status
OFF
Sy󰀬em Errors
ON
Data Logger
Main menu Submenu
See 4.6.1
See 4.6.2
See 4.6.3
See 4.6.4
See 4.6.5
4.6.1 Data Logger Switch On / O󰀨
Starting the logger function.
Symbol Description Setting Status Function
OFF Turned o󰀨 OFF
OFF = Data Logger function is turned o󰀨
ON = Data Logger function is turned on
Note:
This function only works with an USB device.
If this function is active, the USB device mustn’t be removed, otherwise data may be lost!! (Like with Windows – safe
removal of USB devices)
4.6.2 Current Values
Denition of the relay function – acts directly on the relay output:
Symbol Description Setting Status Function
OFF Current value OFF
OFF = Current values of all registered SP are not recorded.
ON = Current values of all registered SP are recorded.
Release of the current value recording of all active measuring points on the USB device in a CSV le. The le name is
generated by the system and can’t therefore be determined manually.
The name of the le is structured as follows:
CVMMTT.csv, with MM standing for the current month and TT standing for the current day.
Every day, a new le with the current date is generated. This makes sure that the les won’t be too big to be still edited
by established PC programs.
Internal structure of the le
