DGC6 – UserManual
Code Gas Type Formula Meas. Range
1
Unit
2072 R401b R401b 20-2000 ppm
2073 R402a R402a 20-2000 ppm
2074 R402b R402b 20-2000 ppm
2082 R403a R403a ppm
2078 R404a R404a 20-300 ppm
2083 R407a R407a ppm
2080 R407c R407c 20-300 ppm
2075 R408a R408a 20-2000 ppm
2076 R409a R409a 20-2000 ppm
2068 R410a R410a 20-300 ppm
2067 R411a R411a 20-300 ppm
2079 R416a R416a 20-300 ppm
2084 R417a R417a 20-2000 ppm
2081 R422d R422d 20-300 ppm
2062 R434a R434a 20-300 ppm
2069 R507 R507 20-2000 ppm
EXT TempC TempC C
EXT TempF TempF F
EXT Humidity Hum. % RH
EXT Pressure Press mbar
EXT TOX TOX ppm
EXT Comb. Comb % LEL
EXT External %
EXT Digital3 %
1
Dierent measuring ranges are possible, but not listed here. For details see the sensor datasheets.
2
Oxygen measurements: Alarm at falling concentration
3
The use with the measuring range value: 1 results in a binary value output of the values 0 or 1.
4.8.3.4 Measuring Range Denition
The measurement range must be adapted to the working range of the connected gas sensor.
For additional control by the installer, the settings in the controller must mandatorily match with the used sensors. If
the types of gas and/or measurement ranges of the sensor don’t agree with the settings of the controller, the error
“EEPROM / conguration error” is generated, and the collective fault message is activated.
The range also aects the display of the measured values, alarm thresholds and hysteresis. For measuring ranges
<10 three decimals places, <100 two decimal places, <1000 one decimal place are displayed. For measuring ranges
=> 1000, the display is without decimal place. The resolution and accuracy of the calculation is not aected by the
dierent measuring ranges.
