46
En
1080p
*2
:
Select this for 1080p output and video conversion as
necessary.
Source:
Output will be according to the resolution level
which was set in the “Picture Adjust” setting
(➔ 55).
•The “Resolution” setting can be set for each “Monitor Out”
setting.
•If the “Monitor Out” setting is set to “Both”, this setting is fixed
at “Auto”.
*1
PC IN (Analog RGB) input signal is output at 720p resolution
when the “Monitor Out” setting is set to “Analog” (➔ 45)
and the “Resolution” setting is set to “Through”.
*2
These settings are not available when the “Monitor Out” set-
ting is set to “Analog”.
HDMI Input
If you connect a video component to an HDMI input, you
must assign that input to an input selector. For example, if
you connect your Blu-ray Disc/DVD player to HDMI
IN 2, you must assign “HDMI2” to the “BD/DVD” input
selector.
If you’ve connected your TV to the AV controller with an
HDMI cable, composite video, S-video and component
video sources can be upconverted
*
and output by the
HDMI output
*1
. You can set this for each input selector by
selecting the “-----” option.
*1
This applies only when “Monitor Out” setting is set to other
than “Analog” (➔ 45).
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, PC,
TV/CD, PHONO, PORT
HDMI1, HDMI2, HDMI3, HDMI4, HDMI5,
HDMI6:
Select the HDMI IN to which the video component
has been connected.
-----:
Output composite video, S-Video, and component
video sources from the HDMI output. The video out-
put signal from the HDMI output is the one config-
ured in “Component Video Input” (➔ 47).
•“AUX” is used only for input from the front panel.
• Each HDMI input cannot be assigned to two input selec-
tors or more. When HDMI1 - HDMI6 have already
been assigned, you must set first any unused input selec-
tors to “-----” or you will be unable to assign HDMI1
- HDMI6 to input selector.
• For composite video, S-Video, and component video upconver-
sion for the HDMI output, the “Monitor Out” setting must be
set to other than “Analog” (➔ 45), and the “HDMI Input” set-
ting must be set to “-----”. See “Video Connection Formats”
for more information on video signal flow and upconversion
(➔ 21).
• If no video component is connected to HDMI output (even if the
HDMI input is assigned), the AV controller selects the video
source based on the setting of “Component Video Input”.
•When an HDMI IN is assigned to an input selector as explained
here, the same HDMI IN will be set as a priority in the “Digital
Audio Input” (➔ 47). In this case, if you want to use the coaxial
or optical audio input, make the selection in the Audio Selector
in the Home menu (➔ 25).
•“TUNER” selector cannot be assigned and is fixed at the
“-----” option.
• If you connect a component (such as UP-A1 Dock that seated
iPod) to UNIVERSAL PORT jack, you cannot assign any input
to “PORT” selector.
• Do not assign the component connected with the HDMI input to
“TV/CD” selector when you set “TV Control” setting to “On”
(➔ 61). Otherwise, appropriate CEC (Consumer Electronics
Control) operation will not be guaranteed.
Input selector Default assignment
BD/DVD HDMI1
VCR/DVR HDMI2
CBL/SAT HDMI3
GAME HDMI4
PC HDMI5
AUX FRONT (Fixed)
TUNER ----- (Fixed)
TV/CD -----
PHONO -----
PORT -----
IN
OUT
Composite video, S-Video,
component video
Composite video, S-Video,
component video
HDMI
HDMI
