95
En
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Input Sensitivity and Impedance
200 mV/47 k (LINE)
2.5 mV/47 k (PHONO MM)
Rated RCA Output Level and Impedance
200 mV/470 (PRE OUT)
Maximum RCA Output Level and Impedance
4.6 V/470 (PRE OUT)
Phono Overload 70 mV (MM 1 kHz 0.5%)
Frequency Response 5 Hz - 100 kHz/+1 dB, -3 dB (Direct mode)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 (Component and S-Video Y)
0.7 Vp-p/75 (Component P
B
/C
B
, P
R
/C
R
)
0.25 Vp-p/75 (S-Video C)
1 Vp-p/75 (Composite
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, -3 dB
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz
AM Tuning Frequency Range
530 kHz - 1710 kHz
Preset Channel 40
Digital Tuner SIRIUS
Power Supply AC 120 V, 60 Hz
Power Consumption 0.5 A
Stand-by Power Consumption
0.2 W
Dimensions
(W
H
D)
435 mm
173.5 mm
365 mm
17-1/8"
6-13/16"
14-3/8"
Weight 8.0 kg (17.6 lbs.)
Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6,
AUX INPUT
Output OUT MAIN, OUT SUB
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, Deep Color,
x.v.Color, LipSync, CEC
Component IN 1, IN 2, IN3
S-Video BD/DVD, VCR/DVR, CBL/SAT, GAME
Composite BD/DVD, VCR/DVR, CBL/SAT, GAME,
AUX
Analog RGB input PC IN
Component MONITOR OUT
S-Video MONITOR OUT, VCR/DVR OUT
Composite MONITOR OUT, VCR/DVR OUT,
ZONE 2 OUT
Digital Optical: 2
Coaxial: 3
Analog BD/DVD, VCR/DVR, CBL/SAT, GAME,
PC, TV/CD, AUX, PHONO
Multichannel Inputs 7.1
Analog VCR/DVR, ZONE 2 PRE OUT
Analog Multichannel Pre Outputs
7
Subwoofer Pre Outputs 2
Phones 1 (6.3 ø)
SETUP MIC 1
RS232 1
Ethernet 1
IR Input 2
IR Output 1
12 V Trigger Out 3
USB 1
Universal Port 1
RI 1
