36
En
Explanatory Notes
Main Menu Input/Output Assign
Monitor Out
You can specify the output resolution for the HDMI OUT
and have the AV receiver upconvert the picture resolution
as necessary to match the resolution supported by your
TV.
■ Resolution
` Through
:
Select this to pass video through the AV receiver at
the same resolution and with no conversion.
` Auto:
Select this to have the AV receiver automatically
convert video at resolutions not supported by your
TV.
` 480p
Select this for 480p output and video conversion as
necessary.
` 720p:
Select this for 720p output and video conversion as
necessary.
` 1080i:
Select this for 1080i output and video conversion as
necessary.
` 1080p:
Select this for 1080p output and video conversion as
necessary.
HDMI Input
If you connect a video component to an HDMI input, you
must assign that input to an input selector. For example, if
you connect your Blu-ray Disc/DVD player to HDMI
IN 2, you must assign “HDMI2” to the “BD/DVD” input
selector.
If you’ve connected your TV to the AV receiver with an
HDMI cable, composite video and component video
sources can be upconverted
*
to HDMI. See “Video Con-
nection Formats” for more information on video signal
flow and upconversion (➔ 19).
Here are the default assignments.
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, PC, TV/
CD, PORT
` HDMI1, HDMI2, HDMI3, HDMI4, HDMI5:
Select a corresponding HDMI input that the video
component has been connected.
` -----:
Select this to output composite video and component
video sources from the HDMI OUT. The video sig-
nal from HDMI output is configured in “Component
Video Input” (➔ 37).
*1
If you connect your personal computer to PC IN, you must
assign “-----” to the “PC” input selector.
• Each HDMI input cannot be assigned to two input selec-
tors or more. When HDMI1 - HDMI5 have already
been assigned, you must set first any unused input selec-
tors to “-----” or you will be unable to assign HDMI1
- HDMI5 to input selector.
Note
•When an HDMI IN is assigned to an input selector as explained
here, the digital audio input for that input selector is automati-
cally set to the same HDMI IN (➔ 37, Digital Audio Input).
• Tuner selector cannot be assigned and is fixed at the “-----”
option.
• If you connect a component (such as UP-A1 Dock that seated
iPod) to UNIVERSAL PORT jack, you cannot assign any input
to Port selector.
• Do not assign the component connected with the HDMI input to
TV/CD selector when you set “TV Control” setting to “On”
Input/Output Assign
Subwoofer
Ye s
:
No:
Main Menu Speaker Setup
b
a
c
a Menu selection
b Setting target
c Setting options (default setting underlined)
Select if a subwoofer is connected.
Select if no subwoofer is connected.
Input selector Default assignment
BD/DVD HDMI1
VCR/DVR HDMI2
CBL/SAT HDMI3
Game HDMI4
PC
HDMI5
*1
Tuner ----- (Fixed)
TV/CD -----
Port -----
IN
OUT
Composite video,
component video
Composite video,
component video
HDMI
HDMI
To Next Page
