Video Resolution Chart

The following tables show how video signals at different resolutions are output by the AV receiver.

✔: Output

Available resolution:

[640

× 480 60/72/75 Hz], [800 × 600 56/60/72/75 Hz], [1024 × 768 60/70/75 Hz], [1280 × 1024 60 Hz]

HDMI COMPONENT COMPOSITE

1080p 1080i 720p 480p 480i 1080p 1080i 720p 480p 480i 480i

HDMI 1080p ✔

1080i ✔✔✔

720p ✔✔✔

480p ✔✔✔✔

480i ✔✔✔✔✔

COMPONENT 1080p ✔✔

1080i ✔✔✔ ✔

720p ✔✔✔ ✔

480p ✔✔✔✔ ✔

480i ✔✔✔✔✔ ✔

COMPOSITE 480i ✔✔✔✔✔ ✔

PC(D-5ub)

✔✔✔✔
