(➔ 48). Otherwise, appropriate CEC (Consumer Electronics
Control) operation will not be guaranteed.
Component Video Input
If you connect a video component to a component video
input, you must assign that input to an input selector. For
example, if you connect your Blu-ray Disc/DVD player to
COMPONENT VIDEO IN 2, you must assign “IN2” to
the BD/DVD input selector.
Here are the default assignments.
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, PC, TV/
CD, PORT
` IN1, IN2:
Select a corresponding component video input that
the video component has been connected.
` -----:
Select if you are using HDMI output, not component
video output, to output composite video and compo-
nent video sources.
Note
• If you connect a component (such as UP-A1 Dock that seated
iPod) to the UNIVERSAL PORT jack, you cannot assign any
input to Port selector.
Digital Audio Input
If you connect a component to a digital audio input, you
must assign that input to an input selector. For example, if
you connect your CD player to the OPTICAL IN 1, you
must assign “OPT1” to the “TV/CD” input selector.
Here are the default assignments.
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, PC, TV/
CD, PORT
` COAX1, COAX2, OPT1, OPT2:
Select a corresponding digital audio input that the
component has been connected.
` -----:
Select if the component is connected to an analog
audio input.
Note
• When an HDMI IN is assigned to an input selector in “HDMI
Input” (➔ 36), this input assignment is automatically set to the
same HDMI IN. And in addition to the usual inputs (e.g.,
COAX1, COAX2, etc.), you can also select HDMI inputs.
• Available sampling rate for PCM signals from a digital input
(optical and coaxial) is 32/44.1/48/88.2/96 kHz/16, 20, 24 bit.
• If you connect a component (such as UP-A1 Dock that seated
iPod) to the UNIVERSAL PORT jack, you cannot assign any
input to Port selector.
Main menu Speaker Setup
Here you can check the settings made by Audyssey 2EQ
Room Correction and Speaker Setup function, or set them
manually, which is useful if you change one of the con-
nected speakers after using Audyssey 2EQ Room Correc-
tion and Speaker Setup function.
Note
These settings are disabled when:
• a pair of headphones is connected, or
•the “Audio TV Out” setting is set to “On”
(➔ 47) and an input
selector other than HDMI is selected.
Speaker Configuration
With these settings, you can specify which speakers are
connected and a crossover frequency for each speaker.
Specify “Full Band” for speakers that can output low fre-
quency bass sounds adequately, for example, speakers
with a good sized woofer. For smaller speakers, specify a
crossover frequency. Sounds below the crossover fre-
quency will be output by the subwoofer instead of the
speaker. Refer to your speaker’s manuals to determine the
optimum crossover frequencies. If you set up your speak-
ers using Audyssey 2EQ
®
Room Correction and Speaker
Setup, please make sure manually that any THX speakers
are set to “80Hz(THX)” crossover.
■ Subwoofer
` Yes
:
Select if a subwoofer is connected.
` No:
Select if no subwoofer is connected.
■ Front
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
to 130Hz, 150Hz, 200Hz
Note
• If the “Subwoofer” setting is set to “No”, the “Front” setting is
fixed at “Full Band”.
Input selector Default assignment
BD/DVD IN1
VCR/DVR - - - - -
CBL/SAT IN2
Game -----
PC -----
Tuner ----- (Fixed)
TV/CD -----
Port -----
Input selector Default assignment
BD/DVD COAX1
VCR/DVR - - - - -
CBL/SAT COAX2
Game OPT1
PC -----
Tuner ----- (Fixed)
TV/CD OPT2
Port -----
Speaker Setup
Some of the settings in this section are set automatically
by Audyssey 2EQ
®
Room Correction and Speaker
Setup function (➔ 23).
To Next Page
