118
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power
All channels: North American:
90 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion
of 0.08% (FTC)
105 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.7% (FTC)
110 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
Australian:
7 ch × 140 W at 6 ohms, 1 kHz, 1 ch
driven (IEC)
Maximum Output Power
7 ch × 175 W at 6 ohms, 1 kHz, 1 ch
driven (JEITA)
Dynamic Power 210 W (3 Ω, Front)
180 W (4 Ω, Front)
110 W (8 Ω, Front)
THD (Total Harmonic Distortion)
0.08%
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE)
Output Level and Impedance
200 mV/2.2 kΩ (REC OUT)
Frequency Response 5 Hz - 100 kHz/+1 dB - 3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
Speaker Impedance North American:
6 Ω - 16 Ω
Australian:
4 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75
Ω
(Component Y)
0.7 Vp-p/75
Ω
(Component P
B
/C
B
, P
R
/C
R
)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 50 MHz - 3 dB
FM Tuning Frequency Range
North American:
87.5 MHz - 107.9 MHz
Australian: 87.5 MHz - 108.0 MHz,
RDS
AM Tuning Frequency Range
North American: 530 kHz - 1710 kHz
Australian: 522 kHz - 1611 kHz
Preset Channel 40
Digital Tuner (North American models only):
SIRIUS
Power Supply North American: AC 120 V, 60 Hz
Australian: AC 230 V, 50 Hz
Power Consumption North American: 5.5 A
Australian: 550 W
Dimensions (W × H × D)
435 × 175 × 326.5 mm
17-1/8" × 6-7/8" × 12-7/8"
Weight 10.9 kg (24.0 lbs.)
HDMI IN 1, IN 2, IN 3, IN 4, IN 5, AUX
Component IN 1, IN 2
Composite DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX
HDMI OUT
Component OUT
Composite MONITOR OUT, VCR/DVR OUT
Digital Inputs Optical: 2
Coaxial: 2
Analog Inputs DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX, TV/TAPE, CD
Analog Outputs TV/TAPE, VCR/DVR,
ZONE2 PRE OUT
Multichannel Pre Outputs
7 (L, R, C, SL, SR, SBL or Front High
L, SBR or Front High R)
Subwoofer Pre Outputs
2
Speaker Outputs Main (L, R, C, SL, SR, SBL, SBR)
+ ZONE2 / Front High (L, R)
Phones 1
MIC Yes
RS232 1
Ethernet 1
IR Input/Output 2/1
12 V Trigger Out 3
DTR-30.1_En_A.book 118 ページ ２００９年４月９日 木曜日 午後１時３０分
