Integra DTR-30.1 User Manual

33
Connecting the AV Receiver—Continued
Connecting a Camcorder or Other Device
Connection AV receiver Signal flow Camcorder etc.
AUX Input Video ⇐ Composite video output
AUX Input L-Audio-R ⇐ Analog audio L/R output
Step 1: Video Connection
Make the connection .
A
Step 2: Audio Connection
Make the connection .
a
AUDIO
OUT
VIDEO
OUT
L R
AUDIO
VIDEO
L R
AUX INPUT
AUX INPUT
A
a
Camcorder, etc.
A
a
