97
Zone 2—Continued
If you’ve connected your Zone 2 speakers to the AV
receiver, as explained in “Connecting Your Zone 2
Speakers Directly to the AV receiver” on page 96, you
must set the “Powered Zone 2” setting to “Act” (Acti-
vated).
Notes:
• When “Act” is selected and Zone 2 turned on, the
Zone 2 speakers connected to the Zone 2 L/R speaker
terminals output sound, but the surround back or front
high speakers connected to the SURR BACK/
FRONT HIGH L/R speaker terminals do not. When
“Act” is selected and Zone 2 turned off, the surround
back or front high speakers output sound as normal.
• When the “Powered Zone 2” setting is set to “Act”
and the input selector of Zone 2 is selected, power
consumption on standby mode slightly increases.
• Powered Zone 2 cannot be used if “Speaker Type” is
set to “Bi-Amp” (see page 44).
• This procedure can also be performed on the AV
receiver by using its [Setup] button, arrow buttons, and
[Enter] button.
Setting the Powered Zone 2
1
Press the [Receiver] button
followed by the [Setup] button.
The main menu appears onscreen.
If the main menu doesn’t appear, make
sure the appropriate external input is
selected on your TV.
2
Use the Up and Down [q]/[w]
buttons to select “2. Speaker
Setup”, and then press [Enter].
The “Speaker Setup” menu appears.
3
Use the Up and Down [q]/[w]
buttons to select “1. Speaker
Settings”, and then press [Enter].
The “Speaker Settings” menu appears.
2. Speaker Setup
1. Speaker Settings
2. Speaker Configuration
3. Speaker Distance
4. Level Calibration
5. Equalizer Settings
4
Use the Up and Down [q]/[w]
buttons to select “Powered
Zone 2”, and use the Left and
Right [e]/[r] buttons to select:
Not Act:
Zone 2 L/R speaker terminals not
activated (Powered Zone 2 dis-
abled).
Act:
Zone 2 L/R speaker terminals acti-
vated (Powered Zone 2 enabled).
5
Press the [Setup] button.
The setup menu closes.
DTR-30.1_En_A.book 97 ページ ２００９年４月９日 木曜日 午後１時３０分
