Integra DTR-7.4 User Manual

25
Connecting to Audio/Video Equipment—Continued
These jacks are for connecting an auxiliary power
amplifier.
You can use an auxiliary power amplifier to listen at
louder volumes than you can with the DTR-7.4 alone.
When using a power amplifier, connect each speaker to
the power amplifier.
Connecting Auxiliary Power Amplifier
DIGITAL
IN
PRE OUT
OPT
2
1
2
FRONT
SUB
SURR
R
L
1
3
SURR
BACK/
ZONE 2
COAX
MULTI
C
INPUT
FRONT
R
L
CENTER
A
RL
INPUT
RL
INPUT
RL
INPUTINPUT INPUT
RL
FRONT
PRE OUT
SUB
SURR
SURR
BACK/
ZONE 2
R
L
R
L
R
L
R
L
R
L
R
L
87654321
Subwoofer
Front
Surround
back
to White
to Red
to Purple
to Blue
to Green
to Gray
Surround
Center
Power amplifier
1. Front left speaker
2. Front right speaker
3. Subwoofer
4. Surround back left
speaker
5. Surround back right
speaker
6. Surround left
speaker
7. Surround right
speaker
8. Center speaker
to Brown
to Tan
Facilities and Connections
