Configuring Input Settings Suitable for Your Connections—Continued
The default settings are given below.
For example, when you connect the DVD player to the
COMPONENT VIDEO INPUT 2 jacks, select “DVD”
as input source and set “b. Component Video” to
“INPUT 2.”
Available component video inputs are “INPUT 1,”
“INPUT 2,” “VIDEO,” “Last Valid,” and “None.”
INPUT 1: The video signals from devices connected to
the INPUT 1 of the COMPONENT VIDEO input banks
are used.
INPUT 2: The video signals from devices connected to
the INPUT 2 of the COMPONENT VIDEO input banks
are used.
VIDEO: The video signals assigned in the “a. Video”
sub-menu setting are used. This option is useful when
no devices are connected to the INPUT 1 and INPUT 2
of the COMPONENT VIDEO input banks.
Last Valid (enables the source last selected): Select to
have the video of the previous input source continued.
None: No video signals are assigned. When you select
“None,” the OSD screen disappears. If you want to
change this setting later on, use the front panel display
on the DTR-7.4.
Input source selected Component video input
CD Last Valid
PHONO Last Valid
TUNER Last Valid
TAPE Last Valid
DVD INPUT 1
VIDEO 1 INPUT 2
VIDEO 2 INPUT 2
VIDEO 3 INPUT 2
VIDEO 4 INPUT 2
VIDEO 5 INPUT 2
NET AUDIO Last Valid
Setting Up Your DTR-7.4
