Intel 1000BASE-T User Manual

1000BASE-T/100BASE-TX/10BASE-T Physical Layer Compliance Tests Manual
Intel Confidential 113
Other Test Fixtures
D.5 10Base-T Balun Test Fixture
D.6 Common-Mode Output Voltage Test Circuit (Fixture
14-14)
Female
RJ-45
Connector
1 2 3 6
North Hills
Wideband
Transformer
Model:
0300BB
100 ohm Bal.
50 ohm Unb.
North Hills
Wideband
Transformer
Model:
0300BB
100 ohm Bal.
50 ohm Unb.
3.1"
4.0"
TD
RD
47.5
ohms
47.5
ohms
49.9
ohms
+TD
-TD
Ecm
+
-
To
Chasis
Ground
Text Fixture 14-14
Common-Mode Output Voltage Test Circuit
A
lli
g
ator
Cli
p
Stake Pin
Stake Pin
RJ-45 Male
Clear epoxy
protective
coating over
the resistors.
1" X 1"
p
erf board
Pin 2
Pin 1
