Intel 1000BASE-T User Manual

Manual Register Settings
1000BASE-T/100BASE-TX/10BASE-T Physical Layer Compliance Tests Manual
132 Intel Confidential
H.2 82541 and 82547 Families
H.3 82544 Family
Test Registers
10Base-T Register Settings
1411.10.02 Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 0000 Reg 4 = 0021 Reg 9 = 1000
1411.10.03 Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 0000 Reg 4 = 0021 Reg 9 = 1000
1411.10.07 Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 0000 Reg 4 = 0021 Reg 9 = 1000
1411.10.09 Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 0000 Reg 4 = 0021 Reg 9 = 1000
1411.10.12
a
a. Set last four digits to 1840 before adjusting other registers.
Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 0000 Reg 4 = 0021 Reg 9 = 1000
1411.10.13
a
Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 0000 Reg 4 = 0021 Reg 9 = 1000
1411.11.05
a
Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 0000 Reg 4 = 0021 Reg 9 = 1000
100Base-Tx Register Settings
9.1.2.2 Reg 0 = 2100 Reg 12 = 0809 Reg 0 = 1800 None None
9.1.5 Reg 0 = 2100 Reg 12 = 0809 Reg 0 = 1800 None None
9.1.6 Reg 0 = 2100 Reg 12 = 0809 Reg 0 = 1800 None None
9.1.8 Reg 0 = 2100 Reg 12 = 0808 Reg 0 = 1800 None None
9.1.9
a
Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 2100 Reg 4 = 0101 Reg 9 = 1000
9.2.2
a
Reg 16 = 41A0 Reg 18 = 0E00 Reg 0 = 2100 Reg 4 = 0101 Reg 9 = 1000
1000Base-T Register Settings
40.6.1.2.1 Reg 0 = 0140 Reg 9 = 3B00 None None None
40.6.1.2.2 Reg 0 = 0140 Reg 9 = 3B00 None None None
40.6.1.2.5 Reg 0 = 0140 Reg 9 = 7B00 None None None
40.8.3.1 Reg 0 = 0140 Reg 9 = 9B00 None None None
40.8.3.3 Reg 0 = 0140 Reg 9 = 9B00 None None None
Test Registers
10Base-T Register Settings
1411.10.02 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.03 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.07 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.09 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.12 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.13 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.11.05 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
