1000BASE-T/100BASE-TX/10BASE-T Physical Layer Compliance Tests Manual
Intel Confidential 131
Manual Register Settings
Appendix H: Manual Register Settings
In some cases, the user may chose to perform the recommended tests manually. This appendix
contains information on the manual register settings that must be completed to perform various
tests in various 1000BASE-T silicon. For information on how to perform the manual test
procedure, please refer to the appropriate IEEE specification document.
Note: Some tests require the same register to be adjusted more than once or in a specific sequence. Adjust
the registers in the order listed from left to right.
H.1 82540 and 82546 Families
Test Registers
10Base-T Register Settings
1411.10.02 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.03 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.07 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.09 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.12 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.10.13 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
1411.11.05 Reg 0 = 8000 Reg 4 = 0021 Reg 9 = 0000 Reg 16 = 3C08
100Base-Tx Register Settings
9.1.2.2 Reg 0 = 2100 Reg 16 = 0F68 Reg 29 = 0002 Reg 30 = 0008
9.1.5 Reg 0 = 2100 Reg 4 = 0101 Reg 9 = 0000 Reg 16 = 0F68
9.1.6 Reg 0 = 2100 Reg 16 = 0F68 Reg 29 = 0002 Reg 30 = 0008
9.1.8 Reg 0 = 2100 Reg 16 = 0F68 Reg 29 = 0002 Reg 30 = 000C
9.1.9 Reg 0 = 2100 Reg 4 = 0101 Reg 9 = 0000 None
9.2.2 Reg 0 = 2100 Reg 4 = 0101 Reg 9 = 0000 Reg 16 = 3B08
1000Base-T Register Settings
40.6.1.2.1 Reg 16 = 0B08 Reg 0 = 8140 Reg 16 = 0F08 Reg 9 = 2200
40.6.1.2.2 Reg 16 = 0B08 Reg 0 = 8140 Reg 16 = 0F08 Reg 9 = 2200
40.8.3.1 Reg 16 = 0B08 Reg 0 = 8140 Reg 16 = 0F08 Reg 9 = 8200
40.8.3.3 Reg 16 = 0B08 Reg 0 = 8140 Reg 16 = 0F08 Reg 9 = 8200
