Technical Reference
46
Table 21. Wake on LAN Header (J1C1)
Pin Signal Name
1 +5 VSB
2 Ground
3 WOL
Table 22. ATAPI CD Audio Connector (J1F1)
Pin Signal Name
1 CD_IN-Left
2 Ground
3 Ground
4 CD_IN-Right
Table 23. ATAPI Telephony Connector
(J2F1)
Pin Signal Name
1 Audio Out (monaural)
2 Ground
3 Ground
4 Audio In (monaural)
Table 24. ATAPI Line In Connector (J2F2)
Pin Signal Name
1 Left Line In
2 Ground
3 Ground
4 Right Line In (monaural)
Table 25. Fan 1 Header (J8M1)
Pin Signal Name
1 Ground
2 FAN_CTRL (+12 V)
3 FAN_SEN*
* If the optional management extension hardware is not available, pin 3 is ground.
