AL440LX Motherboard Product Guide
9
Back Panel I/O Connectors
Figure 2 shows the back panel connectors on the motherboard.
OM06235
DF
C
H
J
A
G
I
B
E
Figure 2. Back Panel I/O Connectors
A PS/2
†
connector (mouse or keyboard) F Serial port 1 connector
B Parallel port connector G Serial port 2 connector
C MIDI/game port connector (optional) H Audio Line Out jack (optional)
D PS/2 connector (mouse or keyboard) I Audio Line In jack (optional)
E USB connectors J Audio Mic In jack (optional)
