2.1.3 Embedded Board Layout (Bottom)
Figure 2 shows the location of the major components on the bottom-side of the
Intel Embedded Board N2800.
Figure 2. Major Board Components (Bottom)
Table 3. Components Shown in Figure 2
Item/callout
from Figure 2
Description
A
Embedded DisplayPort (eDP) connector
