Intel Atom N2800 User Manual


83
Table 41 lists the BIOS Setup program menu features.
Table 41. BIOS Setup Program Menu Bar
Maintenance
Main
Configuration
Security
Power
Boot
Exit
Clears
passwords and
displays
processor
information
Displays
processor
and memory
configuration
Configures
advanced features
available through
the chipset
Sets
passwords
and
security
features
Configures power
management
features and
power supply
controls
Selects
boot
options
Saves or
discards changes
to Setup
program options
Table 42 lists the function keys available for menu screens.
Table 42. BIOS Setup Program Function Keys
BIOS Setup Program
Function Key
Description
<> or <>
Selects a different menu screen (Moves the cursor left or right)
<> or <>
Selects an item (Moves the cursor up or down)
<Tab>
Selects a field (Not implemented)
<Enter>
Executes command or selects the submenu
<F9>
Load the default configuration values for the current menu
<F10>
Save the current values and exits the BIOS Setup program
<Esc>
Exits the menu
4.2 BIOS Flash Memory Organization
The Serial Peripheral Interface Flash Memory (SPI Flash) includes a 32 Mbit (4096 KB)
flash memory device.

Intel Atom N2800 Specifications

General

Processor Number	N2800
Number of Cores	2
Number of Threads	4
Base Frequency	1.86 GHz
TDP	6.5 W
Instruction Set	64-bit
Lithography	32 nm
Launch Date	Q1'12
Instruction Set Extensions	SSE2, SSE3, SSSE3
Embedded Options Available	Yes
Max Memory Size	4 GB
Number of Memory Channels	1
Processor Graphics	Intel® Graphics Media Accelerator 3650
Graphics Base Frequency	640 MHz
Graphics Max Dynamic Frequency	640 MHz
Sockets Supported	BGA559
Max CPU Configuration	1
Idle States	Yes
Intel® 64	Yes
Intel® Identity Protection Technology	No
PCI Express Revision	2.0
Cache	1 MB
Memory Types	DDR3 800
PCI Express Configurations	1x4
