3.5 Mechanical Considerations
3.5.1 Form Factor
The N2800 embedded board is installed into  Mini-ITX form-
factor chassis. Figure 21 illustrates the mechanical form factor of the inside of the
chassis. Dimensions are given in inches [millimeters]. The outer dimensions are 6.7
inches by 6.7 inches [170.18 millimeters by 170.18 millimeters]. Location of the I/O
connectors and mounting holes are in compliance with the ATX specification.

NOTE
The embedded board is designed to have a total height of less than 20 mm from the
underside of the board to the top of its tallest components, including all back panel I/O
ports, internal connectors, installed system memory, and factory-installed thermal
solutions, in compliance with thin mini-ITX requirements per version 2 of the Mini-ITX
Addendum to the microATX Motherboard Interface Specification.
For more information about
Refer to
Thin mini-ITX form factor
http://www.formfactors.org/developer%5Cspecs%5CMini_ITX_
Spec_V2_0.pdf

Intel Atom N2800 Specifications

General

Processor Number	N2800
Number of Cores	2
Number of Threads	4
Base Frequency	1.86 GHz
TDP	6.5 W
Instruction Set	64-bit
Lithography	32 nm
Launch Date	Q1'12
Instruction Set Extensions	SSE2, SSE3, SSSE3
Embedded Options Available	Yes
Max Memory Size	4 GB
Number of Memory Channels	1
Processor Graphics	Intel® Graphics Media Accelerator 3650
Graphics Base Frequency	640 MHz
Graphics Max Dynamic Frequency	640 MHz
Sockets Supported	BGA559
Max CPU Configuration	1
Idle States	Yes
Intel® 64	Yes
Intel® Identity Protection Technology	No
PCI Express Revision	2.0
Cache	1 MB
Memory Types	DDR3 800
PCI Express Configurations	1x4
