Table
33
. PCI
E
xpress Full-/Half-Mini
Card Connector
Pin
Signal Name
Additional Signal Name
1
WAKE#
2
+3.3 V aux
3
Reserved
4
GND
5
Reserved
6
1.5 V
7
CLKREQ#
8
Reserved
9
GND
10
Reserved
11
REFCLK-
12
Reserved
13
REFCLK+
14
Reserved
15
GND
16
Reserved
17
Reserved
18
GND
19
Reserved
20
Reserved
21
GND
22
PERST#
23
PERn0
24
+3.3 V aux
25
PERp0
26
GND
27
GND
28
+1.5 V
29
GND
30
SMB_CLK
31
PETn0
32
SMB_DATA
33
PETp0
34
GND
35
GND
36
USB_D-
37
GND
(mSATA) GND
38
USB_D+
continued
