Intel Atom N2800 User Manual


40
2.13 LAN Subsystem
The LAN subsystem consists of the following:
 Intel 82574L Gigabit Ethernet Controller (10/100/1000 Mbits/s)
 Intel NM10 Express Chipset
 RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
 CSMA/CD protocol engine
 LAN connect interface that supports the Ethernet controller
 Conventional PCI bus power management
 ⎯ Supports ACPI technology
 ⎯ Supports LAN wake capabilities
For information about
Refer to
LAN software and drivers
http://downloadcenter.intel.com
2.13.1 Intel
®
82574L Gigabit Ethernet Controller
The Intel 82574L Gigabit Ethernet Controller supports the following features:
 10/100/1000 BASE-T (IEEE 802.3, 802.3u and 802.3ab) compliant
 IEEE 802.3ab auto negotiation support
 IEEE 802.3x flow control and Auto MDI, MDI-X crossover at all speeds
 Full wake-up support (APM and ACPI 2.0) (Magic Packet* wake-up capable)
 Smart power down at S0 no link and Sx no link
 Jumbo (9kB) frame support
 PCI Express power management support
 TimeSync offload (IEEE1588 and 802.1as) compliant
 Quality of Service (QoS) (802.1p) compliant
 VLAN (802.1q) compliant
 TCP, IP, and UDP checksum offload (for IPv4 and IPv6)
 Transmit TCP segmentation
 Full device driver compatibility
