Intel D102GGC2 User Manual

Intel Desktop Board D102GGC2 Product Guide
12
Table 2. Desktop Boards D102GGC2 Components
Label Description
A PCI bus add-in card connectors
B Front panel audio header
C PCI Express* x1 connector
D PCI Express x16 connector
E Back panel connectors
F 12 V processor core voltage connector (2 x 2)
G Rear fan (3-pin)
H Processor socket
I Processor fan header (4-pin)
J Chassis intrusion connector
K Main power connector (2 x 12)
L Diskette drive connector
M Primary IDE connector
N Secondary IDE connector
O Front chassis fan header (3-pin)
P Serial ATA connectors
Q Alternate front panel power LED header
R Front panel header
S Speaker
T Hi-speed USB 2.0 headers
U BIOS configuration jumper
V Battery
W Standby LED
Related Links:
Go to the following links for more information about:
• Desktop board D102GGC2
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd

Intel D102GGC2 Specifications

General

Number of memory slots	2
Maximum internal memory	2 GB
Supported memory clock speeds	400, 533 MHz
Processor socket	LGA 775 (Socket T)
Number of SATA connectors	4
ATX Power connector (24-pin)	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	micro ATX
Compatible operating systems	Microsoft Windows XP/2000
On-board graphics card	No
Parallel processing technology support	Not supported
Networking features	Fast Ethernet

Weight and Dimensions

Depth	218.44 mm
Width	243.84 mm
