A Error Messages and Indicators
Desktop Board D102GGC2 reports POST errors in two ways:
• By sounding a beep code
• By displaying an error message on the monitor
BIOS Beep Codes
The BIOS also issues a beep code (one long tone followed by two short tones) during POST if the
video configuration fails (a faulty video card or no card installed) or if an external ROM module
does not properly checksum to zero.
Table 10 lists the BIOS codes.
Table 10. Beep Codes
Beep Description
3 No memory
Siren CPU overheat (on reboot)
BIOS Error Messages
When a recoverable error occurs during the POST, the BIOS displays an error message describing
the problem.
Table 11 gives an explanation of the BIOS error messages.
Table 11. BIOS Error Messages
Error Message Explanation
PROCESSOR_THERMAL_TRIP_ERROR CPU was previously shutdown due to a thermal event
(overheating).
MULTI_BIT_ECC_ERROR The firmware has detected that a Multi-Bit ECC Error occurred.
SINGLE_BIT_ECC_ERROR The firmware has detected that a Single-Bit ECC Error occurred.
CMOS_BATTERY_ERROR The firmware has detected that a CMOS battery failure occurred.
CMOS_CHECKSUM_ERROR The firmware has detected that a CMOS Checksum Error
occurred.
CMOS_TIMER_ERROR The firmware has detected that the system date/time has not
been set.
MEMORY_SIZE_DECREASE_ERROR The firmware has detected that the system memory has
decreased.
INTRUDER_DETECTION_ERROR The system chassis was opened.
SPD_TOLER_ERROR SERIAL PRESENCE DETECT (SPD) device data missing or
inconclusive. Properly programmed SPD device data is required
for reliable operation. DDR2 533 MHz memory assumed at
slowest timings.
MEM_OPTIMAL_ERROR The installed amount of memory in Channel A is not equal to the
amount of memory in Channel B. Maximum memory
performance is achieved with equal amounts of memory installed
in each channel.

Intel D102GGC2 Specifications

General

Number of memory slots	2
Maximum internal memory	2 GB
Supported memory clock speeds	400, 533 MHz
Processor socket	LGA 775 (Socket T)
Number of SATA connectors	4
ATX Power connector (24-pin)	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	micro ATX
Compatible operating systems	Microsoft Windows XP/2000
On-board graphics card	No
Parallel processing technology support	Not supported
Networking features	Fast Ethernet

Weight and Dimensions

Depth	218.44 mm
Width	243.84 mm
