Intel Desktop Board D102GGC2 Product Guide
14
Related Links:
Go to the following links or pages for more information about:
• The latest list of tested memory,
http://support.intel.com/support/motherboards/desktop/
• SDRAM specifications,
http://www.intel.com/technology/memory/
• Installing memory, page
31 in Chapter 2
ATI RADEON* XPRESS 200 Chipset
The ATI RADEON XPRESS 200 Chipset consists of the following devices:
• ATI RADEON XPRESS Northbridge
• ATI IXP 450 Southbridge
Graphics Subsystem
Desktop board D102GGC2 includes the following:
• ATI RADEON XPRESS 200 Chipset
• PCI Express x16 connector for graphics expansion
Audio Subsystem
Desktop board D102GGC2 includes a flexible 6-channel audio subsystem based on a High
Definition Audio interface:
The audio subsystem features:
• ATI IXP 450 Southbridge
• Realtek AL803/ALC861 audio codec
• Impedance sensing capability for jack re-tasking
• S/N (signal-to-noise) ratio: 90 dB
• Microphone input supporting:
⎯ Stereo microphone
⎯ Microphone boost
The subsystem includes the following connectors:
• Front panel audio connector, including functionality for:
⎯ Line out
⎯ Microphone in
• Back panel audio connectors that are configurable through the drivers of the audio devices:
⎯ Rear left/right out or Line In
⎯ Front left/right out or Line Out
⎯ Center/LFE out or Mic In

Intel D102GGC2 Specifications

General

Number of memory slots	2
Maximum internal memory	2 GB
Supported memory clock speeds	400, 533 MHz
Processor socket	LGA 775 (Socket T)
Number of SATA connectors	4
ATX Power connector (24-pin)	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	micro ATX
Compatible operating systems	Microsoft Windows XP/2000
On-board graphics card	No
Parallel processing technology support	Not supported
Networking features	Fast Ethernet

Weight and Dimensions

Depth	218.44 mm
Width	243.84 mm
