1 Desktop Board Features
This chapter briefly describes the main features of Intel
®
Desktop Board D102GGC2. Table 1
summarizes the major features of the desktop board.
Table 1. Feature Summary
Form Factor
MicroATX (243.84 millimeters [9.60 inches] x 218.44 millimeters [8.60 inches])
Processor
Support for an Intel
®
processor in the LGA775 package
Main Memory
• Two 240-pin SDRAM Dual Inline Memory Module (DIMM) sockets
• 533/400 MHz single channel DDR2 SDRAM interface
• Designed to support up to 2 GB of system memory
Chipset ATI RADEON* XPRESS 200
• ATI RADEON XPRESS Northbridge
• ATI IXP 450 Southbridge
Graphics ATI RADEON XPRESS 200 Graphics with support for external graphics via a
PCI Express* x16 connector
Audio
• ATI RADEON XPRESS 200 Chipset
• High Definition Audio interface
• Realtek* codec
Expansion Capabilities
• Two PCI bus add-in card connectors
• One PCI Express x16 connector
• One PCI Express x1 connector
Peripheral Interfaces
• Eight USB 2.0 ports
⎯ Four ports routed to the back panel
⎯ Four ports routed to two USB headers
• Four Serial ATA (SATA) channels (1.5 Gb/s)
• Two IDE interfaces with ATA-100 support (four devices)
• One VGA connector
• One diskette drive interface
• One parallel port
• One serial port
• PS/2* keyboard and mouse ports
BIOS
• Intel
®
BIOS
• Support for SMBIOS
• Intel
®
Rapid BIOS Boot
• Intel
®
Express BIOS Update
Power Management
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR)
• Wake on USB, PCI, PCI Express, PS/2, LAN, and front panel

Intel D102GGC2 Specifications

General

Number of memory slots	2
Maximum internal memory	2 GB
Supported memory clock speeds	400, 533 MHz
Processor socket	LGA 775 (Socket T)
Number of SATA connectors	4
ATX Power connector (24-pin)	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	micro ATX
Compatible operating systems	Microsoft Windows XP/2000
On-board graphics card	No
Parallel processing technology support	Not supported
Networking features	Fast Ethernet

Weight and Dimensions

Depth	218.44 mm
Width	243.84 mm
