Intel Desktop Board D845PEBT2 Product Guide
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Up to six USB 2.0 ports
— Four ports routed to the back panel
— Two ports routed to the front panel USB header
• Two IDE interfaces with Ultra DMA-33 and ATA-66/100 support
• Two Serial ATA (SATA) channels, one device per channel
• One diskette drive interface
• One parallel port
• One serial port
• Two 6-channel audio ports
• PS/2
†
keyboard and mouse ports
BIOS
• Intel/AMI BIOS
• 4 Mbit symmetrical flash memory
• Support for SMBIOS
• Intel
®
Rapid BIOS Boot
• Intel
®
Express BIOS Update
RAID
Silicon Image Serial ATA RAID 0, 1
Power
Management
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR) support
• Wake on USB, PCI, RS-232, PS/2, LAN, and front panel
Hardware
Management
Hardware monitor with:
• Three fan sensing inputs used to monitor fan activity
• Remote diode temperature sensing
• Intel
®
Precision Cooling Technology fan speed control that automatically adjusts
chassis fan speeds based on system temperature
• Voltage sensing to detect out of range values
✏
NOTE
For information about Intel desktop boards, including technical product specifications, BIOS
updates, and device drivers, go to the Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop/
