Intel D845PEBT2

Intel Desktop Board D845PEBT2 Product Guide
20
OM14810
CR3H1
Figure 2. Location of Standby Power Indicator
CAUTION
Power supplies used with this board must be able to provide enough standby current to support the
standard Instantly Available (ACPI S3 sleep state) configuration. If the standby current necessary
to support multiple wake events from the PCI and/or USB buses exceeds power supply capacity,
the Intel desktop board may lose register settings stored in memory.
For more information on standby current requirements for this desktop board, refer to the
Technical Product Specification (TPS) by selecting the Technical Documentation link at:
http://developer.intel.com/design/motherbd/
Hardware Management
• Power connectors
• Fan connectors
• Fan speed control (Intel Precision Cooling Technology)
• Resume on Ring
• Wake from USB
• Wake from PS/2 keyboard/mouse
• PME# wakeup support
