Installing and Replacing Desktop Board Components
25
Installing and Removing the Desktop Board
Refer to your chassis manual for instructions on installing and removing the desktop board.
WARNING
Only qualified technical personnel should do this procedure. Disconnect the computer from its
power source before performing the procedures described here. Failure to disconnect the power
before you open the computer can result in personal injury or equipment damage.
✏
NOTES
Refer to Appendix B for regulatory requirements and installation instructions and precautions.
Figure 4 shows the location of the eight mounting holes for Desktop Board D845PEBT2.
OM14812
Figure 4. Desktop Board Mounting Holes
